Description
Grey Metal Tileform Sheets combine timeless tile aesthetics with the durability and efficiency of coated steel. Ideal for a range of applications—from homes to farms and industrial units—these versatile sheets offer a sleek, modern finish in a highly practical package.
Whether you're renovating an older building or finishing a new construction, these roofing sheets are designed to perform and impress. Featuring the advanced GreenCoat® Pural BT finish in Slate Grey, they provide a long-lasting, weather-resistant, and maintenance-free roofing solution.
Key Applications for Grey Metal Tileform Sheets
Perfect for a wide range of projects, including:
-
Domestic homes
-
Commercial properties
-
Agricultural structures
-
Industrial units
-
Heritage and conservation areas
Suitable for:
-
Over-cladding existing roofs
-
External face of built-up insulated systems
-
Roof pitches of 12° or more
Why Choose Grey Metal Tileform Sheets?
Enjoy the traditional look of a tiled roof with the benefits of cutting-edge materials and design:
-
Traditional Appearance, Modern Strength
Offers the look of clay tiles with the performance of high-grade steel. -
Lightweight and Easy to Install
Weighing just 6.6kg/m², these sheets are easy to handle and install. -
Low Maintenance
The durable surface requires no ongoing care—ideal for long-term use. -
Eco-Friendly Materials
Made from sustainable GreenCoat® Pural BT coated steel for environmental peace of mind. -
Visually Seamless
Integrates perfectly into both contemporary buildings and older, sensitive areas. -
Available in Slate Grey
This upgraded finish provides enhanced durability and a refined, modern look.
Product Specifications
-
External Finish: GreenCoat® Pural BT (Slate Grey, 0.7mm thickness)
-
Internal Finish: Grey polyester for a clean, protective underside
-
Sheet Profile: 41/1000 tile profile with a 41mm height and 200mm pitch
-
Standard Width: 1000mm when lapped
-
Maximum Length: Up to 6m
-
Minimum Roof Pitch: 12 degrees
-
Sheet Weight: 6.6kg/m²
-
Thickness Options: Upgraded to 0.7mm for superior durability
-
Purlin Spacing Recommendation: 600mm
-
Installation: Fix with self-drilling fasteners at profile troughs; flashing trims available for a complete finish
Important Notes
-
Graphite Grey Discontinued: Now replaced with Slate Grey GreenCoat® Pural BT finish.
-
Matching Previous Orders? Contact our sales team to ensure colour consistency.
Achieve the timeless look of a traditional tiled roof while enjoying the strength and durability of modern materials with these Tile Effect Roofing Sheets.
Ideal for a wide range of applications including domestic, industrial, commercial, and agricultural buildings, these metal tile sheets are as versatile as they are reliable.
Whether you're looking to over clad an existing roof or enhance the external face of a built-up insulated system, these sheets deliver quality and long-lasting performance.
Perfect for roof pitches of 12 degrees or higher, they’re the ultimate roofing solution for both new builds and older properties.
Key Benefits of Roof Tile Sheets:
- Traditional Look, Modern Performance: Get the classic look of a tiled roof with the strength and durability of modern coated steel sheets.
- Strong Yet Lightweight: These sheets are robust but easy to handle, making installation simple and efficient.
- Maintenance-Free: With a durable surface finish, your new roof will require no ongoing maintenance.
- Blends Seamlessly: Ideal for both contemporary buildings and culturally sensitive areas, these sheets maintain an authentic appearance while providing advanced protection.
- Eco-Friendly: Manufactured using Greencoat® colour coated steel, an environmentally friendly material that extends the lifespan of your roof.
-
Available in a Range of Colours: Choose from a variety of colours to match the aesthetic of your building.
Specifications:
- Application: Suitable for roof installations
- External Finish: Coated with GreenCoat® Mica BT for superior protection and durability
- Internal Finish: Grey polyester for a clean and durable underside
- External Face: 41/1000 tile sheet, 41mm profile height with a 200mm pitch
- Standard Width: 1000mm when lapped
- Maximum Length: Up to 6m for extended coverage
- Minimum Pitch: 12 degrees
- Gauge Thickness: 0.6mm for robust and reliable roofing
- Weight: 6.6kg/m², making it lightweight yet strong
- Suggested Purlin Spacing: 600mm for optimal support
- Installation: Can be installed using conventional self-drilling fasteners at the lower point of the profile. Flashing trims provide a complete, cost-effective system.
For dripstop, contact our sales team: info@tradewarehouse.co.uk
