Description
The Freefoam 10mm Solid uPVC Soffit Board, also known as a General Purpose Board, is designed to finish and protect the underside of the roofline between the fascia and the external wall.
Its solid, flat profile creates a clean soffit finish and is available in a wide range of widths, making it suitable for everything from standard domestic eaves to deep soffits and large box-end details.
Supplied in practical 5 metre lengths, the board is low maintenance, easy to cut on site and available in several popular Freefoam colours and woodgrain finishes.
Why Choose Freefoam General Purpose Soffit Board?
-
Solid 10mm uPVC construction
Creates a clean, rigid soffit finish beneath the roof overhang.
-
Made for roofline applications
Ideal for finishing the underside of eaves between the fascia board and property wall.
-
Huge choice of widths
Available from 100mm through to 605mm, allowing you to select a board that properly matches the soffit depth.
-
Excellent for deep soffits and box ends
The wider boards are particularly useful where a large roof overhang or substantial box-end detail needs covering.
-
5 metre board length
Long lengths help reduce unnecessary joints across straightforward roof runs.
-
Low-maintenance uPVC
No regular painting, staining or timber treatment is required.
-
Can be cut on site
Boards can be trimmed to suit individual eaves dimensions, corners and roof details.
-
Matching Freefoam trims available
Use compatible soffit joints, starter trims, wall trims and corners to complete the installation neatly.
Where Is This Board Used?
- Domestic roof soffits
- Extensions and new-build properties
- Garages and outbuildings
- Deep roof overhangs
- Large box-end construction
- General external roofline finishing
How Is Soffit Board Installed?
The board is normally installed horizontally beneath the eaves and fixed to suitable timber soffit bearers or supporting battens. The fascia forms the outer roof edge, while the rear of the soffit is finished against the wall using the appropriate Freefoam trim or support detail.
-
Measure the soffit depth first
Measure from the rear support position to the fascia so you can choose the correct board width. -
Provide suitable support
The soffit should be fixed to sound, correctly positioned timber supports rather than left unsupported across large spans. -
Cut boards accurately
Boards can be cut on site using suitable fine-toothed cutting tools. -
Use the correct finishing trims
Joints and perimeter trims help support board edges and produce a cleaner roofline. -
Allow for normal uPVC movement
Follow Freefoam installation guidance for fixing centres and expansion allowances.
Important Ventilation Note
This is a solid, non-vented soffit board. Where the roof construction requires ventilation at the eaves, suitable separate ventilation must be provided, such as a ventilation strip or another approved roof ventilation method.
If you specifically want ventilation already incorporated into the soffit board, choose the Freefoam Vented Soffit range instead.
Product Specifications
- Brand: Freefoam
- Product type: Solid uPVC soffit board / General Purpose Board
- Length: 5000mm / 5m
- Thickness: 10mm
- Available widths: 100mm to 605mm
- Material: PVC-U / uPVC
- Application: External soffits, eaves and box-end construction
- Finish: Solid flat board
Choosing the Right Width
Do not simply guess the soffit size. Measure the actual underside of the roof overhang from the fascia back towards the wall or soffit support.
Narrower boards suit compact eaves, while the 300mm, 405mm, 450mm, 500mm and 605mm options become particularly useful on deeper soffits and larger box-end details.
Frequently Asked Questions
Is this a fascia board?
No. This board is primarily used as a soffit beneath the roofline. The fascia is the vertical board fixed along the outer roof edge.
Is the board vented?
No. This is the solid Freefoam General Purpose Board. If roof ventilation is required, separate ventilation must be incorporated or a purpose-made vented soffit board should be used.
Can the 5m board be cut down?
Yes. It can be cut on site to suit the required soffit depth and roofline dimensions.
What are the wider boards used for?
Wider sizes are especially useful for deep soffits, broad roof overhangs and large box-end construction where a standard narrow soffit board would not provide enough coverage.
Do I need soffit trims?
Usually, yes. The exact trims depend on the roof detail, but suitable joints, edge trims and wall trims help support and neatly finish the soffit installation.
A Versatile Soffit Board for Everyday Roofline Work
With widths from 100mm right through to 605mm, the Freefoam 10mm Solid uPVC Soffit Board gives roofers and builders plenty of flexibility for standard eaves, deep soffits and larger box ends. Its 5m length, low-maintenance finish and broad colour range make it a practical choice for both roofline refurbishment and new-build work.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
PVC Soffit Boards — Quick Order & Calculator
Find the right soffit boards and finishing trims in minutes. Choose hollow, solid or pre-vented uPVC soffits, match your colour and width, and build a materials estimate with upfront trade pricing.
Choose Your Soffit Board
Start with the finish you want. We'll show only colours and sizes available in your chosen range.
Choose Your Soffit Boards & Finishing Trims
No filtering through hundreds of SKUs. Change the quantity before you add anything.
Which Trims Do I Actually Need?
J trim helps start and finish soffit edges, especially against the wall. H joint joins two cut or full board ends. External corner trim covers outward-facing changes of direction. H-vent provides a separate continuous ventilation route when the roof design requires it. Matching colours are shown where stocked; contrasting white is never selected automatically.
Need Fascia Boards or PVC Guttering Too?
We also stock PVC fascia boards, guttering and downpipes. Finish building your soffit estimate first, then use our main website menu to find the other roofline products.
Estimate guidance only. Actual cutting patterns, effective installed coverage, roof ventilation, fixing centres, expansion gaps and substrate support must be verified against the appropriate manufacturer instructions and site conditions. Fixings and ventilation materials are not included unless explicitly selected.
