Description
The Freefoam 200mm uPVC Fascia Capping Board is designed for renovating an existing roofline where the original timber fascia is still structurally sound. Rather than removing the whole fascia system, this 10mm cover board fits over the existing board to create a clean, low-maintenance uPVC finish.
With a generous 200mm width and 5 metre length, it is particularly useful on deeper fascia runs where narrower cover boards would not provide enough coverage. A wide range of stocked colours also makes it easy to coordinate the roofline with windows, doors, guttering and soffits.
Why Choose the Freefoam 200mm Fascia Cover Board?
-
Designed for fascia capping
Made specifically for covering suitable existing timber fascia rather than replacing it completely. -
Deeper 200mm width
Provides greater vertical coverage for properties with a broader existing fascia board. -
10mm cover board profile
A slim uPVC capping board designed to sit over a sound supporting fascia behind. -
Supplied in 5 metre lengths
Helps keep joins to a minimum across longer roof runs for a cleaner finished appearance. -
Low-maintenance uPVC
No regular painting or staining is required once the roofline has been correctly installed. -
Excellent choice of colours
Available in White, popular contemporary shades and traditional woodgrain-effect finishes. -
Can be cut on site
The board can be trimmed to suit roof dimensions, corners and individual installation details. -
Matching Freefoam accessories available
Compatible joints, corners and other finishing pieces can be used to complete the roofline neatly.
Available Stocked Colours
- White
- Anthracite Grey Foil
- Anthracite Grey Smooth Foil
- Black Ash
- Matt Black Smooth Foil
- Chartwell Green Foil
- Cream Foil
- Light Oak
- Mahogany
- Rosewood
This gives the 200mm range plenty of flexibility. Anthracite Grey and Matt Black work particularly well on modern properties, while Light Oak, Mahogany and Rosewood are useful when matching traditional timber-effect windows or existing exterior joinery.
Why the 200mm Width Matters
The 200mm cover board is intended for rooflines where a narrower 150mm or 175mm board does not give enough face coverage. This can be common on properties with deeper eaves or larger existing timber fascia.
Before ordering, measure the actual fascia depth that needs covering rather than assuming the existing board is a standard size. Also consider how the fascia meets the soffit, guttering and any roofline trims, as these details can affect the width required.
Cover Board or Full Replacement Fascia?
This is one of the most important things to get right when choosing your fascia.
-
200mm Reveal Cover Board – 10mm thick
Used to cap an existing fascia that is still sound, secure and suitable to remain in place. -
200mm Magnum Fascia – 18mm thick
Used where the original fascia is removed and a full replacement fascia board is required.
Do not use a cover board simply to hide rotten or badly deteriorated timber. If the existing fascia is soft, split, loose or structurally compromised, the underlying issue should be dealt with before the new roofline is installed.
Product Specifications
- Brand: Freefoam
- Range: Reveal Cover Board
- Product type: uPVC fascia capping board / cover board
- Length: 5000mm / 5m
- Width: 200mm
- Thickness: 10mm
- Material: PVC-U / uPVC
- Application: External roofline refurbishment
Ideal for Roofline Renovation
If the existing wooden fascia is still doing its job but looks tired or needs repeated repainting, over-capping it with uPVC can be a sensible way to refresh the roofline.
The 200mm board is especially useful for:
- House roofline refurbishment
- Extensions and garages
- Deeper existing timber fascia
- Replacing a painted fascia finish with low-maintenance uPVC
- Matching grey, black or woodgrain windows and doors
Important Installation Advice
The existing fascia behind the cover board must be sound and securely fixed. The 10mm uPVC board itself should not be treated as the structural support for the guttering or roof edge.
Where gutter brackets are fitted, suitable fixings should pass through the uPVC fascia cover board and secure into the supporting timber behind. Always follow the appropriate Freefoam installation guidance for fixing centres, joints and allowance for movement.
It is also worth checking the condition of the soffit and roof ventilation while the fascia is being refurbished. Capping the fascia should not obstruct any ventilation required at the eaves.
Delivery Information
Stocked colours are normally delivered within 2–3 working days from the point of order. Larger quantities and certain UK delivery areas may occasionally require a little longer.
Frequently Asked Questions
Is this a replacement fascia board?
No. This is a 10mm fascia capping board designed to cover suitable existing fascia. For full replacement, look at the 18mm Freefoam Magnum fascia range.
Can I fit this over old timber fascia?
Yes, but only if the timber is sound, secure and suitable to remain in place. Rotten or structurally damaged fascia should not simply be covered.
Why would I choose 200mm instead of 175mm?
The 200mm board gives an additional 25mm of vertical coverage and is useful where the existing fascia is deeper.
Can the board be cut down?
Yes. The 5m board can be cut on site to suit the dimensions of the roofline.
What is the difference between Anthracite Grey Foil and Anthracite Grey Smooth Foil?
Both are Anthracite Grey, but the Smooth Foil option has a flatter, more contemporary surface appearance compared with the traditional textured foil.
Are matching corners and joints available?
Yes. Matching Freefoam roofline accessories are available separately to help create a neat and consistent finish.
A Practical Capping Board for Deeper Fascia
The Freefoam 200mm uPVC Fascia Capping Board is a strong option when existing timber fascia is still sound but needs a cleaner, easier-to-maintain finish. The wider 200mm face gives useful additional coverage, while the 10mm profile keeps it clearly suited to over-capping rather than full structural replacement.
